Intrinsic® EN10241 Galvanised Mild Steel Fittings

Intrinsic® EN10241 threaded pipe fittings conform to EN 10241:2000 (previously BS1740 wrought iron fittings). They are primarily used for steel threaded pipe systems that convey steam, water, air, gas, oil and other non-corrosive fluids and are known for their strengthand reliabilty - particularly in demanding industrial applications.

Standard		Connection Type
BS EN 10241		Female BSP taper threads/Male BSP parallel threads - EN10226-1/ISO 7-1 (except longscrews and running nipples where parallel threads are to ISO 228-1

Material		Maximum Operating Pressure
Self colour (black) mild steel - finished with a light oil film to prevent rust		PN25 (25 bar)

Maximum Operating Temperature		Operating Temperature Range
230°C		0°C to 230°C
