Table F Non-Asbestos Fibre Full Face Flange Gasket

Table F Non-Asbestos Fibre Full Face Flange Gasket

A Table F full face WRAS Approved non-asbestos PG-X compressed fibre flange gasket to BS7531 Grade X.

Description

PG-X is a high performance grade of compressed fibre sheet material based on aramid and inorganic fibres with a nitrile binding system.

Application

PG-X is a superior performance material meeting the requirements of BS7531 Grade X and with outstanding mechanical properties. It is suitable for many fluids including hydrocarbons, gases, dilute acids and alkalis.

Typical Physical Properties

Thickness:1.5mm1
Density:1.8g/cc
Tensile Strength:ASTM F15214Mpa
Compression:ASTM F36J7% to 15%
Recovery:ASTM 36J65%
Residual Stress:BS7531 (40N/mm² @ 300&176;26MPa
Gas leakage:BS75310.5 ml/min
ASTM Oil 1:ASTM F1462.5%
ASTM Oil 3:ASTM F1465.0%
ASTM Fuel B:ASTM F1464.0%
Code Description Price Quantity
016TFFF015 1/2" NB Table F Full Face Flange Gasket
£1.09 (exc VAT) each
£1.31 (inc VAT)
-
+
016TFFF020 3/4" NB Table F Full Face Flange Gasket
£1.22 (exc VAT) each
£1.46 (inc VAT)
-
+
016TFFF025 1" NB Table F Full Face Flange Gasket
£1.44 (exc VAT) each
£1.73 (inc VAT)
-
+
016TFFF032 1 1/4" NB Table F Full Face Flange Gasket
£1.65 (exc VAT) each
£1.98 (inc VAT)
-
+
016TFFF040 1 1/2" NB Table F Full Face Flange Gasket
£1.97 (exc VAT) each
£2.36 (inc VAT)
-
+
016TFFF050 2" NB Table F Full Face Flange Gasket
£2.43 (exc VAT) each
£2.92 (inc VAT)
-
+
016TFFF065 2 1/2" NB Table F Full Face Flange Gasket
£4.59 (exc VAT) each
£5.51 (inc VAT)
-
+
016TFFF080 3" NB Table F Full Face Flange Gasket
£3.41 (exc VAT) each
£4.09 (inc VAT)
-
+
016TFFF100 4" NB Table F Full Face Flange Gasket
£4.52 (exc VAT) each
£5.42 (inc VAT)
-
+
016TFFF125 5" NB Table F Full Face Flange Gasket
£5.76 (exc VAT) each
£6.91 (inc VAT)
-
+
016TFFF150 6" NB Table F Full Face Flange Gasket
£6.71 (exc VAT) each
£8.05 (inc VAT)
-
+
